| Rated Frequency(Hz) |
50 |
60 |
| Rated power(KVA) |
0.7 |
| Max. power(KVA) |
0.8 |
| Rated voltage(V) |
230 |
120/240 |
| Rated current(A) |
3.04 |
5.82/2.92 |
| Rated ratation speed(r/min) |
6000 |
| DC output(KVA) |
12V-4A |
| Phase NO. |
Single |
| Current circuit breaker |
Without |
| Starting system |
Recoil starter |
| Noise level(zero load¡«full load)[dB(A)/7m] |
60-65 |
| Fuel tank capacity(L) |
1.6 |
| Set fuel consumption(g/kw.h) |
420 |
| Continuous running hour(hr) |
4 |
| Fuel type |
Automotive unlead gasoline |
| Lobe type |
SAE10W30(above CC grade) |
| Structure type |
Portable |
| Overall dimension(LxWxH)(mm) |
395x221x350 |
| Dry weight(kg) |
9.5 |
| Engine model |
EG40 |
| Engine type |
Single cylinder, four-stroke, OHV, gasoline engine |
| Bore X Stroke |
40x30 |
| Displacement (Ml) |
38 |
| Compression ratio |
8.5 |
| Ignition system |
T.C.I |
